Ridgid Threader 1224 1/2-4″ (No Stand)

THREADING MACHINE(no stand)      1224

Capacity:      Pipe   1/4” 4”, 4”-6” using 161 geared threader
         Bolt:   1/4”-2”, (6-52mm) up to 30 Rockwell C

Technical Specifications:
Motor:         1.1kw, single phase 50Hz induction type
Motor control:      Reverse/off/forward heavy duty, rotary type
            and integral footswitch
Spindle speed:      36/12 RPM
Gearbox:         Two speed gear box 3:1 Ratio
Chuck:         Hammer type with replaceable jaw inserts
Rear centering device: Cam action
Cutter:         Model 764 full floating, self centering 1/4:-4”
            with F229 cutter wheel
Reamer:         Model 744, 1/4”-4” blade type
Oiling:         Adjustable flow through the head
Pump:         Self-priming, Geroter type, automatic reversing
            constant flow

Standard equipment
Oil:         5 liters thread cutting fluid
Tools and equipment: 4 hex keys, HD F229 cutter wheel
3/4” combination Wrench, tool box
Die heads:      1 Model 911 1/4-2”, 1 Model 914 2 1/2”-4
Dies:      1set each 1/2”- 3/4”, 1”–2”euto dies and 2 1/2”-4” HS dies

CODE

RID26107
